• Stop When Full
• Multiple protection
• Waterproof grade IP54
• Output power up to 7KW
• Swipe card and scan code to charge, touch screen
• Cold-rolled steel + electrostatic spraying, the shell is
strong, anti-compression, anti-impact
| ELECTRICAL TECHNICAL REFERENCE | |||
| Model | VE2024 | VE3024 | VE4024 |
| Capacity(VA) | 2000W | 3000W | 4000W |
| lnput Voltage(DC) | 24V/48V | 24V/48V | 24V/48V |
| Nominal Voltage | 220VAC | ||
| Voltage Range | 154-265VAC (AC Model); 185-264VAC+3V (UPS Model) | ||
| Frequency | 50-60HZ Auto sensing | ||
| Rated Power | 0.8 | ||
| Voltage | 220VAC | ||
| Frequency | 50/60HZ | ||
| Waveform | Pure Sine Wave | ||
| Transfer Time (AC to DC) | <8ms | ||
| Transfer Time (DC to AC) | <8ms | ||
| Output Voltage Regulation | ±10% | ||
| Bypass Mode | Yes | ||
| Saver Mode | Yes | ||
| Efficiency | >98% | ||
| Input Protection | Circuit Breaker | ||
| Output Protection | Circuit Breaker | ||
| Battery Type | AGM-Deep Cycle, Ge/Up to 500Ah | ||
| Charging Current | 28A | 40A | 60A |
| Low Level disconnect (Selectable) | 10V or 10.5V 20V or 21V | ||
| PWM(Optional) controller Voltage | 15VDC-30VDC 30VDC-60VDC | ||
| MPPT(Optional) controller Voltage | 15VDC-150VDC 30VDC-150VDC | ||
| Maximum PV array power | 1600W | 3200W | |
| Maximum PV array open circuit voltage | PWM:30VDC, MPPT:150VDC | PWM:60VDC | |
| Maximum solar charge current | 60A | ||
| Protections | Over load, over temp, over charging, battery low, battery reverse connect, high AC voltage etc. | ||
| LCD indicator status | AC input voltage, AC input frequency, PV voltage, PV current, Output Voltage, Output Frequency,Battery voltage,Load current etc. |
||
| LED indicator status | AC Line ln: Green/Inverter: Green/Charging: Yellow/Alarm: Red | ||
| LOW battery alarm | Audible alarm-5 seconds beeping | ||
| Overload alarm | Audible alarm- continuous beeping | ||
| Fault | Audible alarm- continuous beeping | ||
| Temperature | 0-40℃ | ||
| Humidity | -10℃~90℃ Non condensing | ||
| Accoustic Noise(db) | >55dB | ||
| Rated Power | 1600W | 2400W | 3200W |
